Description
- Robust design, built to last – Constructed from high-strength, lightweight aluminium, providing a durable and sturdy structure, yet lightweight for easy handling. The gantry can support weights up to 200kg (31 stone 6lb), ensuring reliable performance.
- Versatile – With an adjustable track length of 1.9 – 2.85m and height of 2.14-2.51m, you can be confident it will fit various room sizes and ceiling heights. This makes it an ideal temporary solution and eliminates the need for costly and time-consuming structural modifications.
- Easy to install – The gantry is easy to install without tools. A single person can install it, although we recommend a 2-person assembly. The ratchet system ensures a secure and stable installation while levelling bubbles on the uprights allow for easy levelling and adjustments during installation.
- Safety features offer peace of mind – The safety latch prevents the uprights from retracting, providing an additional layer of safety during use. Floor-level adjusters enhance stability by providing a stable base and maintaining a secure foundation.
- Easy to use – The easy-slide trolley facilitates smooth and effortless movement along the track, enhancing the overall user experience and assisting with various transfers, including from bed to chair. This safe and secure lifting solution offers well-being and dignity to users and carers alike, extending the time people can stay in their own homes.
- Warranty - A 5-year warranty is included as standard.*
Detailed Specification
Weights and dimensions
- Safe working load: 200kg (31 stone 6lb)
- Unit weight: 22.7kg
- Track weight: 6.8kg
- Side posts and foot weight: 9.1kg
- Horizontal length: 2,445 –3,387mm
- Horizontal travel: 1,900 – 2,850mm
- Internal clearance: 2,102 – 3,052mm
- Height range: 2,141 – 2,507mm
- Foot length: 1300mm
Details
- Material: Anodised aluminium
For full technical specifications, please refer to the datasheet.
